Pedal operated hydraulic control valve
This Pedal shows reduced overall dimensions and several configurations. It controls one valve working section.
Type: Single pedal
Nr. of Ports: 2
Nominal Flow Rating l/min – (US gpm): 12 (3,2)
Max. Pressure bar – (psi): 100 (1450)
Specifications:
No. of Spools: 1-3
Special Features: No HPCO Fitted, HPCO Fitted, 114 LPM – 30 US GPM
Max Flow: 114 LPM – 30 US GPM
Max Pressure: 206 bar – 3000 PSI
Port Size: 1-1/16” UN O’Ring
Manufacturer: Cross
Specfications
Working section number: 1 – 12
Rated flow: 150 l/min – 40 GPM
Rated pressure: 350 bar – 5000 PSI
Spool stroke: 7 + 7 mm
Spool pitch: 46 mm
Circuit type: Parallel, series, tandem
Specifications
Working section number: 1 – 12
Rated flow: 700 l/min – 185 GPM
Rated pressure: 350 bar – 5000 PSI
Spool stroke: 15 + 15 mm
Spool pitch: 91 mm
Circuit type: Parallel
