Description
Standard
| Model | GPM | PSI | LPM | Bar | Size | Technical Data | 3D |
| IM-CVA | 8 | 3000 | 30 | 207 | 5/8-18 | Download | |
| MA-CVA | 5 | 3500 | 19 | 241 | 5/8-18 | Download | |
| HB-CVA | 10 | 4350 | 38 | 300 | 3/4-16 | Download | |
| DE-CVA | 15 | 3500 | 57 | 241 | 7/8-14 | Download | |
| HE-CVA | 15 | 5000 | 57 | 345 | 7/8-14 | Download | |
| HT-CVA | 35 | 5000 | 132 | 345 | 1 1/16-12 | Download | |
| SJ-CVA | 40 | 3500 | 151 | 241 | 1 5/16-12 | Download | |
| DE-CVB | 10 | 3500 | 38 | 241 | 7/8-14 | Download | |
| PB-CVC | 10 | 3500 | 38 | 241 | 3/4-16 | Download | |
| DE-CVC | 8 | 3500 | 30 | 241 | 7/8-14 | Download |
Standard – Soft Seat
| Model | GPM | PSI | LPM | Bar | Size | Technical Data | 3D |
| MA-CVS | 2.5 | 1500 | 9.5 | 103 | 5/8-18 | Download | |
| PB-CVS | 5 | 3500 | 19 | 241 | 3/4-16 | Download | |
| DE-CVS | 10 | 1000 | 38 | 70 | 7/8-14 | Download |
Reverse Flow
| Model | GPM | PSI | LPM | Bar | Size | Technical Data | 3D |
| DE-CRV | 15 | 3500 | 57 | 241 | 7/8-14 | Download | |
| HT-CVR | 35 | 5000 | 132 | 345 | 1 1/16-12 | Download |
Check With Thermal Relief
| Model | GPM | PSI | LPM | Bar | Size | Technical Data | 3D |
| DE-CVT | 15 | 4000 | 57 | 276 | 7/8-14 | Download |
