Wheel, Shaft Output and Spindle Output Drives are continuously ordered to meet the power requirements for conveyors, augers, and mixers.
| WHEEL DRIVES | ✓ |
| SHAFT OUTPUT DRIVES | ✓ |
| SPINDLE OUTPUT DRIVES | ✓ |
| WHEEL DRIVES | SHAFT OUTPUT DRIVES | SPINDLE OUTPUT DRIVES |
| ✓ | ✓ | ✓ |
| MAX CONTINUOUS OUTPUT TORQUE Nm | 19,800 |
| MAX INTERMITTENT OUTPUT TORQUE Nm | 39,600 |
| MAX INPUT SPEED DOUBLE REDUCTION RPM | 4,000 |
| MAX RADIAL LOAD CAPACITY Kgf | 16,300 |
| RATIOS | 19.52-45.00:1 |
| HYDRAULIC MOTOR MOUNTING | SAE C,D |
Wheel, Shaft Output and Spindle Output Drives are continuously ordered to meet the power requirements for conveyors, augers, and mixers.
| WHEEL DRIVES | ✓ |
| SHAFT OUTPUT DRIVES | ✓ |
| SPINDLE OUTPUT DRIVES | ✓ |
Wheel, Shaft Output and Spindle Output Drives are continuously ordered to meet the power requirements for conveyors, augers, and mixers.
| WHEEL DRIVES | ✓ |
| SHAFT OUTPUT DRIVES | ✓ |
| SPINDLE OUTPUT DRIVES | ✓ |
Wheel, Shaft Output and Spindle Output Drives are continuously ordered to meet the power requirements for conveyors, augers, and mixers.
| WHEEL DRIVES | ✓ |
| SHAFT OUTPUT DRIVES | ✓ |
| SPINDLE OUTPUT DRIVES | ✓ |
Wheel, Shaft Output and Spindle Output Drives are continuously ordered to meet the power requirements for conveyors, augers, and mixers.
| WHEEL DRIVES | ✓ |
| SHAFT OUTPUT DRIVES | ✓ |
| SPINDLE OUTPUT DRIVES | ✓ |
